The RF Line
Wideband Linear Amplifiers
designed for amplifier applications in 50 to 100 ohm systems requiring wide bandwidth, low noise and low distortion. This hybrid provides excellent gain stability with temperature and linear amplification as a result of the push–pull circuit design.
• Specified Characteristics at VCC = 15 V, TC = 25°C:
 Frequency Range — 10 to 1000 MHz
Output Power — 1 W Typ @ 1 dB Compression, f = 900 MHz
Power Gain — 15.5 Typ @ f = 1000 MHz
PEP — 1 W Typ @ – 32 dB IMD
Noise Figure — 7.5 dB Typ @ f = 500 MHz
ITO — 40.5 dBm @ f = 1000 MHz
• All Gold Metallization for Improved Reliability
• Optimized for 15 Volt Operation

CA5815C,MHW707-1
