FAST HIGH VOLTAGE DIODE
FEATURES AND BENEFITS
● SPECIFICTO”FREEWHEELMODE”OPERATIONS: FREEWHEEL OR BOOSTER
DIODE.
● ULTRA-FAST RECOVERY.
● VERY LOW OVERALL POWER LOSSES IN BOTH THE DIODE AND THE COMPANION TRANSISTOR.
● HIGH FREQUENCY OPERATIONS.
● INSULATED PACKAGE: ISOTOP Electrical insulation : 2500VRMS Capacitance< 45 pF

DESCRIPTION
The TURBOSWITCH is a very high performance series of ultra-fast high voltage power diodes from 600V to 1200V. TURBOSWITCH family, drastically cuts losses in both the diode and the associated switching IGBT or MOSFET in all ”freewheel mode” operations and is particularly suitable and efficient in motor control freewheel applications and in booster diode applications in power factor control circuitries. Packaged either in ISOTOP or SOD93these 600V devices are particularly intended for use on 240V domestic mains.

STTA12006TV1
