Standard type

NOTE: Mounting bracket is not supplied with the sensor. Please select from the range of optional sensor mounting brackets.

Notes:
1) The model No. with "E" shown on the label affixed to the thru-beam type sensor is the emitter, "D" shown on the label is the receiver.
(e.g.) Emitter of CX-411: CX-411E, Receiver of CX-411: CX-411D
2) The sensing range of the retroreflective type sensor is specified for the RF-230 reflector. The sensing range represents the actual sensing range of the sensor. The sensing ranges itemized in "A" of the table below may vary depending on the shape of sensing object. Be sure to check the operation with the actual sensing object.

NEW Basic type

(Without operation mode switch and sensitivity adjuster. Cable is0.5 m0.02 inlong)

NOTE: Mounting bracket is not supplied with the sensor. Please select from the range of optional sensor mounting brackets.

Notes:
1) The model No. with "E" shown on the label affixed to the thru-beam type sensor is the emitter, "D" shown on the label is the receiver.
(e.g.) Emitter of CX-411A-C05: CX-411E, Receiver of CX-411A-C05: CX-411AD
2) The reflector is sold separately.
3) The sensing range of the retroreflective type sensor is specified for the RF-230 (optional) reflector. The sensing range represents the actual sensing range of the sensor. The sensing ranges itemized in "A" of the table below may vary depending on the shape of sensing object. Be sure to check the operation with the actual sensing object.

0.5 m 1.640 ft/5 m16.404 ftcable length types

0.5 m1.640 ft/5 m16.404 ftcable length types (standard:2 m6.562 ft, basic:0.5 m1.640 in) are also available.
When ordering this type, suffix "-C05" for the0.5 m1.640 ftcable length type, "-C5" for the5 m16.404 ftcable length type to the model No.
(Excluding CX-44□ and basic type.)
(e.g.)
0.5 m1.640 ftcable length type of CX-411-P is "CX-411-P-C05"
5 m16.404 ftcable length type of CX-411-P is "CX-411-P-C5"

M8 plug-in connector type, M12 pigtailed type

M8 plug-in connector type and M12 pigtailed type are also available.
When ordering this type, suffix "-Z" for the M8 connector type, "-J" for the M12 pigtailed type to the model No.
(Please note that M12 pigtailed type is not available for CX-44□. Excluding basic type.)
(e.g.)
M8 connector type of CX-411-P is "CX-411-P-Z"
M12 pigtailed type of CX-411-P is "CX-411-P-J"

-Mating cable (2 cables are required for the thru-beam type.)

Mating cable
CN-24A-C2 CN-24A-C5		CN-24AL-C2 CN-24AL-C5		CN-22-C2, CN-22-C5 CN-24-C2, CN-24-C5

Package without reflector

NPN output type: CX-491-Y
PNP output type: CX-491-P-Y

Accessory

RF-230 (Reflector)

CX-411D,CX-411E,CX-421-P-Z,EX-14A,EX-14A-PN,MQ-W70C-DC12-24V
